SKF NJ 2220 ECML Bearings wholesale price | On sale

                                                                                    INQUIRY

      Dimensions
Product net weight  5.32 kg
d
100 mm Bore diameter
D
180 mm Outside diameter
B
46 mm Width
d1
≈127 mm Shoulder diameter of inner ring
D1
≈156.4 mm Shoulder diameter of outer ring
F
119 mm Raceway diameter of inner ring
r1,2
min.2.1 mm Chamfer dimension
r3,4
min.2.1 mm Chamfer dimension
s
max.2.5 mm Permissible axial displacement


SKF performance class
SKF Explorer
Basic dynamic load rating C
380 kN
Basic static load rating C0
450 kN
Fatigue load limit Pu
54 kN
Reference speed

4 000 r/min

Limiting speed
6 700 r/min
Minimum load factor kr
0.3
Limiting value e
0.3
Calculation factor Y

0.4
